Transport carriage

118 Service Instructions 755 A/756 A - 00.0 - 02/2019

18.3 Changing the toothed belt

Fig. 120: Changing the toothed belt (1)

WARNING

Risk of injury from moving parts!

Crushing possible.

Switch off the machine before changing the toothed

belt.

(1) - Screws

(2) - Screw

(3) - Screws

(4) - Toothed belt

(5) - Screws

(6) - Toothed belt cover

①

①③

①

②

③

①

⑤

④

⑥
