DURKOPP ADLER 755 A

Setting the trimming and clamping device for the needle threads
86 Service Instructions 755 A/756 A - 00.0 - 02/2019
12.1 Testing the function of the trimming and clamping device
for the needle threads
Fig. 89: Testing the function of the trimming and clamping device for the needle threads
To check the function of the trimming and clamping device for the needle
threads:
1. Press the pneumatic switch (5) on the machine head.
(5) - Pneumatic switch
⑤
