Needle bar
34 Service Instructions 755 A/756 A - 00.0 - 02/2019
6.1.3 Changing the needle holder
Fig. 21: Changing the needle holder
To change the needle holder:
1. Disassemble the middle knife.
2. Remove the needles.
3. Loosen the screw (3).
4. Unscrew the needle holder (2) from the needle bar (1).
5. Screw in a new needle holder all the way.
Next, turn the needle holder back until the screw (3) can be tightened
in the slotted hole.
6. Tighten the screw (3).
Order
Finish by checking the height of the needle bar ( p. 32).
(1) - Needle bar
(2) - Needle holder
(3) - Screw
