Automatic corner knife station (straight/slanted pocket)
Service Instructions 755 A/756 A - 00.0 - 02/2019 157
 The display switches to:
Fig. 154: Testing and adjusting the corner knives electrically (2)
Symbols Meaning
Set corner knife correction seam begin. left
• Value range: -13 - 13
• the knife supports must be parallel to one another
Set corner knife correction seam end left
• Value range: -13 - 13
• the knife supports must be parallel to one another
Set corner knife correction seam begin.
• -99.9 mm - 99.9 mm
Set correction corner knife seam end
• -99.9 mm - 99.9 mm
