(11) Line Spacing Setting
Line spacing of the receipt and slip is different.
A: First line printing
B: Second line printing
[Example 1] When
n = 5 for
ESC 3
n
A
B
9 dots
Slip:
Approcimately 8.82 mm (5/144 inches)
A
B
24 dots
Receipt:
Approcimately 3.53 mm (5/360 inches)
For the receipt, if the line spacing is shorter than the height of a character, line feed is
executed for the height of the character.
[Example 2] When the height of a character is doubled.
Slip:
A
18 dots
8 dots
Line spacing
(default)
B
A
48 dots
Line spacing (default)
B
Receipt:
Slip:
Receipt (When front A (12´24 dots) is selected):
