Specification
(STANDARD)
· 24-dot bit image for the receipt paper
MSB
d1
LSB
d4 d7
d2 d5 d8
d3 d6 d
Print data
Bit-image data
d1 d2 d3
Bit-image data
Print data
1 dot
d4 d5 d6 d7 d8 d9
Single density
Double density
· 8-dot bit image for slip paper
MSB
d1
LSB
d2 d3
Print data
Bit-image data
d1 d2 d3
Bit-image data
Double density
Print data
1 half dot
Single density
