CONFIDENTIAL
SHEET
169
NO.
SHEET
REVISION
E
TITLE
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
NEXT
170
Fourth byte (paper sensor information)
Bit Off/On Hex Decimal Status for ASB
0 Off 00 0 Slip is selected.
On 01 1 Slip is not selected.
1 Off 00 0 Can print on slip.
On 02 2 Cannot print on slip.
2, 3 - - - Undefined.
4 Off 00 0 Not used. Fixed to Off.
5, 6 - - - Undefined.
7 Off 00 0 Not used. Fixed to Off.
Bit 0: Bit 0 is 1 (slip is not selected) when selecting a MICR function.
Bit 1: Bit 1 is 0 when the slip is set (can print) and Bit 1 is 1 when the slip ejection starts
(cannot print).
· When the slip is selected and the printer waits for the slip to be inserted, bits 5
and 6 of third byte are 1 (paper not present), Bit 0 of forth byte is 0 (slip is
selected) and Bit 1 of fourth byte is 1 (cannot print on slip).
· When printing stop due to paper end of a slip is disabled by
ESC c 4
, if there is
no printable area on the slip, Bit 1 of fourth byte is not On (cannot print on slip).
Check if there is printing area on the slip by using
GS r 3
.
[Default]
n
= 0 when DIP SW 2-1 is off,
n
= 2 when DIP SW 2-1 is on.
[Reference]
DLE EOT
,
ESC c 4
,
GS r
, Appendix E,
Transmission Status Identification
