Third byte (paper sensor information)
Bit Off/On Hex Decimal Status for ASB
0 Off 00 0 Paper roll near-end sensor: paper adequate.
On 01 1 Paper roll near-end sensor: paper near end.
1 Off 00 0 Paper roll near-end sensor: paper adequate.
On 02 2 Paper roll near-end sensor: paper near end.
2 Off 00 0 Paper roll end sensor: paper present.
On 04 4 Paper roll end sensor: paper not present.
3 Off 00 0 Paper roll end sensor: paper present.
On 08 8 Paper roll end sensor: paper not present.
4 Off 00 0 Not used. Fixed to Off.
5 Off 00 0 TOF sensor: paper present.
On 20 32 TOF sensor: paper not present.
6 Off 00 0 BOF sensor: paper present.
On 40 64 BOF sensor: paper not present.
7 Off 00 0 Not used. Fixed to Off.
For bits 2 and 3, when the paper roll cover is open, paper detection may be incorrect.
