Epson TM-H5000II series User Manual

CONFIDENTIAL
SHEET
27
NO.
SHEET
REVISION
E
TITLE
NEXT
28
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
2.1.2.4 Electrical Characteristics
DC Characteristics (Except Logic-H, +5 V signals)
Specifications
Characteristics Symbol
Min Max
Conditions
Output HIGH voltage V
OH
*2.4 V 5.5 V *I
OH
=0.32mA
Output LOW voltage V
OL
-0.5 V *0.4 V *I
OL
=-12mA
Output HIGH current I
OH
0.32 V - V
OH
=0.32V
Output LOW current I
OL
-12 V - V
OL
=0.4V
Input HIGH voltage V
IH
2.0 V -
Input LOW voltage V
IL
- 0.8 V
Input HIGH current V
IH
- -0.32 mA V
IH
=2.0V
Input LOW current V
IL
- 12 mA V
IL
=0.8V
Logic-H Signal Sender Characteristics
Specifications
Characteristics Symbol
Min Max
Conditions
Output HIGH voltage V
OH
3.0 V 5.5 V
Output LOW voltage V
OL
- 2.0 V While the power is
OFF
+5 V Signal Sender Characteristics
Specifications
Characteristics Symbol
Min Max
Conditions
Output HIGH voltage V
OH
*2.4 V 5.5 V *IOH=0.32mA
Output LOW voltage V
OL
-- **
While the power is OFF
Output HIGH current I
OH
- 0.32 mA VOH=2.4V
Output LOW current I
OL
- ** -
While the power is OFF
** No guarantee is offered to V
OL
and I
OL
while the power is OFF.
