2) DIP switch 2: 8 switches
Table 3.3.3 DIP Switch 2
SW 2 Function ON OFF
1 Handshaking (BUSY condition) Receive buffer full Off line or receive
buffer full
2 Customer display (DM-D) connection Connected Not connected
3 Refer to Table 3.3.4
4
Selects print density / Receipt low
power consumption mode
5 Internal use Fixed to Off
6 Internal use Fixed to Off
7 I/F pin 6 reset signal Enabled Disabled
8 IF pin 25 reset signal Enabled Disabled
Table 3.3.4 DIP Switch 2-3 and 2-4
Level Function SW 2-3 SW 2-4
-- Low power consumption mode ON ON
1
Print density (Normal) OFF OFF
2ONOFF
3 Print density (Dark) OFF ON
NOTES:
· When pin 6 of the interface connector is used for the reset signal, the printer is
reset at MARK on the RS-232 level.
· When pin 25 of the interface connector is used for the reset signal, the printer is
reset at SPACE on the RS-232 level or at HIGH on the TTL level.
· Changes in DIP switch settings (excluding switches 2-7 and 2-8 interface reset
signals) are recognized only when the printer power is turned on or when the
printer is reset by using the interface. If the DIP switch setting is changed after the
printer power is turned on, the change does not take effect until the printer is turned
on again or is reset.
· If you turn on DIP switch 2-7 or 2-8 while the printer power is turned on, the printer
may be reset, depending on the signal state. DIP switches should not be changed
while the printer power is on.
· If the print density is set to level 2 or 3, printing speed is inclined to be low speed.
· In low power consumption for receipt, printing speed is fixed to 70 mm/sec.
