3.3.3.2 Parallel interface specification (TM-H5000
II
IIII
II
P/TM-H5000
II
IIII
II
PM)
Table 3.3.5 DIP Switch 1
SW Function ON OFF
1 Handshaking (BUSY condition) Always enabled Always disabled
2 Receive buffer capacity 45 bytes 4K bytes
3-8 Undefined --- ---
Table 3.3.6 DIP Switch 2
SW Function ON OFF
1 Handshaking (BUSY condition)
Receive buffer full Off-line or Receive
buffer full
2 Internal use (Do not change settings) --- Fixed to Off
3 Refer to Table 3.3.7
4
Selects print density / Receipt low
power consumption mode
5-7 Internal use (Do not change settings) --- Fixed to Off
8 I/F pin 31 reset signal
(Do not change settings)
Fixed to On ---
Table 3.3.7 DIP Switch 2-3 and 2-4
Level Function SW 2-3 SW 2-4
-- Low power consumption mode ON ON
1
Print density (Normal) OFF OFF
2ONOFF
3 Print density (Dark) OFF ON
NOTES: · Changes in DIP switch settings (excluding switch 2-8, interface reset signal) are
recognized only when the printer power is turned on or when the printer is reset by
using the interface. If the DIP switch setting is changed after the printer power is
turned on, the change does not take effect until the printer is turned on again or is
reset.
· If the DIP switch 2-8 is turned on while the printer power is turned on, the printer
may be reset, depending on the signal state. DIP switches should not be changed
while the printer power is on.
· If the print density is set to level 2 or 3, printing speed is inclined tol be low speed.
· In a low power consumption for receipt, printing speed is fixed to 70 mm/sec.
