POWERHEAD
POWERHEAD ASSEMBLY
lower housing with exte nded lip facing down.
Lubricate seal lip with Triple-Guard grease.
Install a new O-ring on the lower ho using. Before
installing cr ankshaft into cylin der block, apply a
thin coat of Gasket Sealing Compound to outer
edge of O-ring.
Place lower seal housing on crankshaft.
Lubricate upper main bearing with outboard lubri-
cant and install on crankshaft.
Pack lip of upper o il seal with Moly Lube. Place
seal o n crankshaf t wit h lip do wn and enclosed
face up. Do not apply sealer to outside edge of the
seal.
1. Seal lip 002036
002037
1. Lower seal housing
2. O-ring
002038
1. Upper main bearing 002033
1. Upper oil seal 002034
