278
MIDSECTION
TILLER HANDLE SERVICE – LONG HANDLE
Remove locknuts from screws on top of steering
arm.
Remove th e screws att aching tiller bracket to
steering arm. Remove tiller bracket and handle.
Disassembly
Loosen th rottle frict ion control so the re is no
restriction on grip.
IMPORTANT: Do not back screw out com-
pletely. Nut is under spring tension.
Remove seven screws and bottom cove r of tiller
handle.
Remove stop swi tch cover s crews, un plug st op
switch electrical connector and remove st op
switch assembly.
1. Screw 006362
1. Screw 006361
1. Throttle friction control 006711
1. Cover screw 006566
006713
