RECOIL STARTER CLEANING AND INSPECTION
14
RECOIL STARTER
CLEANING AND
INSPECTION
Wash met al components in solvent and dry with
compressed air.
Inspect the rewind sp ring for broken end lo ops
and weak tension.
Examine the starter pawl for wear.
Inspect the starter components for wear. Replace
as necessary.
Inspect st arter rope. Re place rop e if frayed. Cut
new rope 96.5 in. (245 cm) in length. Fuse ends of
rope to a length of 1/2 in. (12 mm).
Examine the pulley and the starter housing. Look
for shar p edge s an d rough surf aces that cou ld
fray the starter rope. File and polish to remove.
Examine the st arter and starter lockout p arts.
Replace any worn or damaged parts.
RECOIL STARTER
ASSEMBLY
Place starter spring shield and pulley bushing into
the starter housing.
Clamp base of Starter Spring Winder and Installer,
P/N 392093, in a vise. Inse rt release plate in to
spring winder base.
A WARNING
Wear safety glasses while disassembling
and assembling manual starters because
of rewind spring tension.
1. Shield COA1360
1. Base
2. Plate
CO3593
