215
POWERHEAD
UPPER MOUNT SERVICING (3-CYLINDER)
10
UPPER MOUNT
SERVICING (3-Cylinder)
Removal
Remove mount retainer screw.
Insert suit able pun ch in t aper o f mou nt ret ainer.
Tap side of punch to loosen mount retainer.
Dislodge mount assemblies and remove.
Inspect mounts and replace if necessary.
IMPORTANT: The motor mount , washer , and
screw are serviced as an assembly. Do not disas-
semble.
Installation
Place mount assemblies in position, with flats fac-
ing away from each other.
Apply Moly Lube to all sides of retainer and install
between mounts.
Install the retainer screw and tighten to a torque of
15 to 20 ft. lbs. (20 to 27 N·m).
002069
002130
002132
39820
002133
002134
