Evinrude E-tec 75 HP - Page 241

MIDSECTION
SERVICE CHARTS
239
11
STERN BRACKET, 90 HP MANUAL TILT
A
A
18-20 Ft. lbs.
(24-27 N·m)
F
38-45 Ft. lbs.
(52-61 N·m)
40-50 Ft. lbs.
(61-68 N·m)
A
A
B
130-150 Ft. lbs.
(176-204 N·m)
A
A
8-12 In. lbs.
(0.9-1.4 N·m)
28-30 Ft. lbs.
(38-41 N·m)
F
60-84 In. lbs.
(7-9.5 N·m)
F
60-84 In. lbs.
(7-9.5 N·m)
F
60-84 In. lbs.
(7-9.5 N·m)
A
F
60-84 In. lbs.
(7-9.5 N·m)
40 Ft. lbs. (54 N·m)
Marine Sealant
18-20 Ft. lbs.
(24-27 N·m)
18-20 Ft. lbs.
(24-27 N·m)
18-20 Ft. lbs.
(24-27 N·m)
60-84 In. lbs.
(7-9.5 N·m)
A
110-130 Ft. lbs.
(149-176 N·m)
F
60-84 In. lbs.
(7-9.5 N·m)
F
18-20 Ft. lbs.
(24-27 N·m)
A Triple-Guard Grease
B Gasket Sealing Compound
C Adhesive 847
D Moly Lube
E Red Ultra Lock
F Blue Nut Lock
G Needle Bearing Grease
P Permatex No. 2
Q Gel Seal II
008204
IMPORTANT
Use
Triple-Guard grease
on all pivot points
