274
MIDSECTION
TILLER HANDLE SERVICE – STANDARD
Install the metal outer handle over the plastic inner
handle and drive the outer handle into place.
Secure tab of th e inner handle int o recess of the
outer handle with the steel pin.
Install the handle en d of the th rottle ca ble. Snap
the th rottle cable tru nnion into the recess in the
handle. Install the retainer clip.
Install the throttle control plate on outer handle.
Push the th rottle cable pin throug h the end of t he
throttle cable.
Lubricate e nd of t he pin, guides, rollers, h elix
grooves, an d inner handle g uide slot with Moly
Lube. Place the guides over the roller pin and into
the slots of t he inner handle. Place the rollers on
the ends of th e roller p in. Assemble the h elix
halves o n th e h andle a nd slide the grip over t he
helix.
31202
24285
1. Throttle cable trunnion
2. Retainer clip
24282
24286
1
2
1. Throttle control plate 24295
24294
24293
1
