332
GEARCASE SERVICE, 75 – 90 HP MODELS
SHIFTER, BEARING AND SEAL SERVICE
Shift Housing Assembly
IMPORTANT: Clean and inspect all parts before
beginning assembly p rocedures. Replace an y
damaged parts.
Lightly coat the detent ball and spring with Needle
Bearing grease. In sert the spring in th e ho using,
then the ball.
Insert shifter detent at 90° a ngle into the h ousing
as shown, while depressing t he ba ll and spring
with a suitable tool. Once the shifter detent is past
the ball, remove th e too l an d po sition detent to
engage NEUTRAL position.
Thoroughly grease 25 needle bearings wit h Nee-
dle Bearing grease and place in the bearing case
(“O” Type gearcases).
With shif ter detent in NEUTRAL, in stall arms of
shift le ver into dete nt slot s. Align the pivot holes
and insert th e re taining p in. Push shif ter detent
down.
Rest the cradle on the shift shaft.
4518
DSC02506
4520
1. Shifter detent
2. Shift lever
3. Pin, shift lever
DSC02449
TYPICAL
1. Cradle
2. Shift shaft
4512
