System manual CECX / Commissioning of CoDeSys and control
Example: Development PC and control in the same network.
hub / switch
IP addr. 192.168.181.1
subnet m. 255.255.255.0
IP addr. 192.168.181.3
subnet m. 255.255.255.0
IP addr. 192.168.181.2
subnet m. 255.255.255.0
IP addr. 192.168.181.4
subnet m. 255.255.255.0
Development PC and control in the same network
A free IP address must be selected for the control.
Information:
Check with a ping command whether the IP address selected for the con-
trol is free (= no reaction to ping command).
Subnet mask can be taken over by the PC (readable with command
ipconfig)
A Gateway entry is not required (can be 0.0.0.0).
CECX-II 7-9
