Page #15 background image
CECX modular control system
Functionality / functions Setting
Basis, area Fixed setting
Size (code) 6 MB
Size per segment (global) 14 MB
Size (marker) 8 KB
Size (input) 8 KB
Size (output) 8 KB
Size retain 128 KB 1)
Own retain segment on/off On
Size of the entire data memory 20 MB
Maximum number of global data
segments
1
Target system settings Memory partitioning
Maximum number of modules 4096
1) Of these 12 bytes are used by the runtime system, and the rest of 131060 bytes can be used by the
application.
Functionality / functions Supported
I/O configuration: configurable Yes
I/O configuration: Download as file No (added to
program code)
I/O configuration: No address check Yes / can be
set
Supporting CANopen configuration Yes
Supporting profibus configuration Yes
Supporting preemptive multi-tasking Yes / fixed
Online change Yes / can be
set
Updating used IOs Yes / can be
set
Single-task in multi-tasking No
Byte addressing Yes / fixed
Zero initialization Yes / fixed
Sending symbol file Yes / can be
set
Symbol configuration from INI file No
PLC browser Yes
Trace recording Yes
Target system settings General
VAR_IN_OUT as reference Yes / fixed
CECX-I 7
