Specifications
(Specifications are subject to change without notice)
Table 1: Specifications
Receiver
Receiver Frequency Range 12kHz-60MHz
1
IP3 (2kHz Tone Spacing) +30.3dBm (Preamp MED), 19.3dBm (Preamp HIGH)
2
IMD DR3 (2kHz Tone Spacing) 103.5dB (Preamp MED), 100.2dB (Preamp HIGH)
2
MDS -131dBm (Preamp HIGH), -121dBm (Preamp MED)
2
Minimum Tuning Step 1Hz (DDS down to µHz)
DDS Clock 200MHz, <1ps RMS jitter
Max. Receive Bandwidth 192kHz (Limited by sound card)
Transmitter
Transmitter Frequency Range 160-6m Bands (2m transverter IF optional)
Transmit Power 100W HF 160-10m w/optional amp
3
, 500mW 6m
Controls
Control Interface PC Parallel Port (DB-25 connector) or optional USB
Rear Panel Control Outputs
15 pin D-connector for external TR relay and band control relays
Input Controls PTT foot switch, Code Key, Microphone
Audio Interface Line In, Line Out, Speaker Out, Microphone In
General
Enclosure Dimensions 10" W x 9.5" D x 4.5" H (25.4cm x 24.1cm x 11.4cm)
Power Supply Requirement 13.8VDC @ 1.25A (Max). 25A with optional 100W PA
4
1
An optional filter bank is supplied that can be configured for bands below 160m. Requires external user supplied pre-selector for best
operation below 160m
2
Sound Card: Edirol FA-66 @ 96kHz sampling rate.
3
40W continuous carrier (100% duty cycle)
4
We recommend the Astron SS-30 or SS-30M or equivalent power supply for the SDR-1000
2 FlexRadio Systems
