O P E R A T I O N C H A P T E R 1 0
Initial Settings
1. Follow the Power Up Procedure, described above. Then click the On button (14). Set the following
controls as specified.
Table 10: Initial Control Values for CW Transmission
Ctrl Value
Reference to
Figure Above
VFO A 14.05MHz (1)
RX Meter Signal (4)
TX Meter Fwd Pwr (4)
Band 20m (5)
Mode CWU (6)
Filter 500Hz (7)
Display Mode Panadapter (9)
Sub RX Off (10)
XIT Off (12)
RIT Off (12)
AF 50 (21)
RF 68 (22)
Drive 50 (23)
AGC Med (24)
Preamp Med (25)
2. Connect a 50 ohm dummy load or tune VFO A (1) to a quiet frequency on the selected band. If
using the 100W PA, use the TUN button (20) to verify power output on the TX Meter (Set to Fwd
Pow). If using the integrated ATU, select Full on the ATU Mode selection (19) and then click the
TUN button (20). See the section below on ATU Operation for more on how to use the ATU.
CAUTION: If not using the ATU and not using a 50 ohm dummy load, ensure the
antenna presents a 50 ohm load with a low SWR or damage may occur to
the SDR output transistor.
[The rest of this page has been left blank intentionally]
137 ď›™FlexRadio Systems
