O P E R A T I O N C H A P T E R 1 0
Note: The red cross-hairs will only be available when either Sub RX (10) or
SPLT (12) (or both) is activated. Clicking will then tune the SUB RX
frequency and/or the transmit frequency (check Show TX Filter on
Display (8) to visualize the latter).
Hint: You can very quickly center a CW, AM or FM signal after click tuning it
by clicking the 0 Beat (12) button on the Front Console (make sure the
display AVG (9) button is on to enable 0 Beat).
Keyboard Keys
Use he following keys on your keyboard to tune the VFO.
Numeric Keypad : Key any frequency in MHz (e.g. 7.250) into the numeric keypad and hit enter to
immediately jump to that frequency.
Mapped Keys : You can map keys on your keyboard to tune each of the digits in VFO A using the
Keyboard Tab on the Setup Form.
Ctrl +Arrow Keys : Hold the Control key and press the
o Up or Down Arrow key to tune VFO A up or down by the Tune Step (2).
o Right or Left Arrow key to increase or decrease the Tune Step (2).
USB Tuning Knob
Both the Griffin PowerMate and the Contour Designs Shuttle Pro v2 can be used to tune the radio. See the
FlexRadio Systems website for documents describing how to setup and use these controllers.
[The rest of this page is intentionally left blank]
132 FlexRadio Systems
