H A R D W A R E S E T U P C H A P T E R 5
Hint: For optimal (low latency) performance connect the key or paddles to a PC
serial port instead (see the section on the Setup Form-DSP Tab, Keyer
Sub-Tab in chapter 8 for more information).
(12) To Line Out (speaker output) on Sound Card – Green color-coded.
(13) To Amplified Speaker or high impedance headphones.
Note: Do not use if using one of our recommended sound cards (Delta-44 or
Edirol FA-66). Instead for best performance and to enable monitoring,
connect your speaker(s) directly to the sound card.
(14) To Line In on Sound Card – Blue color-coded.
(15) To Microphone Input on Sound Card -- Pink or Magenta color-coded. (This connector is directly
connected to the corresponding pins on the front panel mic connector.)
[The rest of this page has been left blank intentionally]
