2.11.7 Color Coding
The switch and ports are displayed in different colors, as described in Table 2.9.
Table 2.9 -
Switch and Port Display Colors
Object Color Means
Switch
Body
Gray The switch is operational (the software is loaded and run-
ning) and it can be contacted by FORE Stack View via the
network.
Dark blue That switch is selected, and various device-specific parame-
ters can be changed using the right-mouse button.
Ports Dark green Port enabled, but no plug connected.
Light green Port enabled and plug connected.
Brown Port disabled by management or a hardware error.
Dark blue That port is selected, and various port-specific parameters
can be changed using the right-mouse button.
Purple Port mirroring is enabled here.
Stack border Dark blue The stack is selected, and various stack-specific parameters
can be changed using the right-mouse button.
Everything;
switches, ports and
stack border
Light blue FORE Stack View has lost contact with the devices (for
example, the switch or your PC is disconnected from the
LAN).
