Right Side and Rear View
Note
• Phone connector and wall jack connector are available only on the model with the fax function.
Internal View
1 USB Port 4 Wall Jack Connector
2 Ethernet Port 5 Power Cord Connector
3 Phone Connector 6 Wireless LAN Kit (Optional)
1 Toner Cartridges 3 Waste Toner Container
2 Drum Cartridges 4 Fusing Unit
Important
• Do not touch as it is hot.
