1.4 Machine Overview
1.4.1 Front, Left Side, Right Side, Rear, and Internal
View
Front and Left Side View
1 Document Glass Cover 7 Tray 2 (One Tray Module) (Optional)
2 Document Glass 8 Stand (Cabinet) (Optional)
3 Operator Panel 9 Left Side Cover [B]
4 Output Tray 10 Tray 5 (Bypass)
5 Front Cover 11 Front USB Port (Optional)
6 Tray 1 (Standard Tray) 12 Left Side Cover [A]
2
1
3
5
7
9
6
11
10
4
8
12
