Tools:
– Phillips PH2 / (+) No. 2 screw driver
– Hexagon screw driver 5 mm (not valid for Japan)
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the fan holder" on page 60.
Removing the defective SAS expander board
▶
Remove the SAS expander board holder, see "Removing the SAS
expander board holder" on page 198.
▶
Remove the SAS expander board, see "Removing the defective SAS
expander board" on page 158.
Installing the new SAS expander board
▶
Install the SAS expander board, see "Installing the new SAS expander
board" on page 160.
▶
Install the SAS expander board holder, see "Installing the SAS expander
board holder".
Concluding steps
▶
"Installing the fan holder" on page 61.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
Hard disk drive (HDD) / solid state disk (SSD)
200 Upgrade and Maintenance Manual RX2520 M5
