Tools: Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the crossbar" on page 62.
▶
If applicable, "Removing the expansion card" on page 237.
Replacing the M.2 SSD
▶
Remove the defective M.2 SSD, see "Removing the M.2 SSD" on page 410.
▶
Install the new M.2 SSD, see "Installing the M.2 SSD" on page 407.
Concluding steps
▶
If applicable, "Installing the expansion card" on page 231.
▶
"Installing the crossbar" on page 63.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
Software configuration
To install the ESXi to the M.2 SSD, see "Software configuration" on
page 409.
System board and components
412 Upgrade and Maintenance Manual RX2520 M5
