Fujitsu PRIMERGY TX1310 M1

110 Upgrade and Maintenance Manual TX1310 M1
System fans
Figure 57: Pushing the HDD cage from the system fan 1
Ê Push the HDD cage in the direction of the arrow to loosen the system fan 1.
Figure 58: Position of the bushings
The bushings remain at the HDD cage. It is not necessary to remove them.
