GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 5 Components and Functions (Theory) 5-35
Table 5-18 Connector K- Op Console Power, Audio, Mic, Control
Pin Signal Pin Signal Pin Signal
1 Standby LED 0 13 +15V 25 nc
2 nc 14 + 15V Ground 26 nc
3On/Off SW115 nc 27 USB 5V
4 On/Off SW0 16 nc 28 USB Ground
5 +12V 17 MIcrophone 29 USB 5V
6 +12V Ground 18 Microphone Ground 30 USB Ground
7 +12V 19 Shield Power/Control 31 USB D+
8 +12V Ground 20 Shield Audio/Mic 32 USB D-
9 +12V 21 Audio - Left 33 Shield USB
10 +12V Ground 22 Audio - Left Ground 34 nc
11 +15V 23 Audio - Right
12 + 15V Ground 24 Audio - Right Ground
Table 5-19 Connector L- Console Microphone
Pin Signal
1 Microphone
Microphone Ground
