4•6 Reference Guide
○○○○○○○○○○○○○○○○○○○○○○
4•6 Reference Guide
LOAD SINGLE REAL PERFORMANCE
Loads a single Performance to any of the 64 lo-
cations of the Performance Groups (1-8). The
incoming Performances overwrite those in RAM.
The original factory-set Performances can be re-
stored at any time with the Restore Performance
operation.
LOAD SINGLE USER STYLE
Loads a single User Style and associated User
Style Performances to any location in the USER
Style Groups (1-4).
LOAD SINGLE STYLE PERFORMANCE
Loads a single bank of up to 8 user-programmed
Style Performances to the original ROM Style
Performance bank. These Performances can-
not be loaded to locations other than the original
source Style Performance bank. For example,
the Style Performances of Style 59 cannot be
loaded to any other location of the ROM Styles.
If you attempt to load to a destination other than
the correct one, a user message will inform you
of your error with the following message:
Press ESCAPE to close the message and try
again, this time selecting the correct destination.
LOAD SINGLE SOUND (EXAMPLE)
Use a disk known to contain a Sample to load to
memory, or load from Hard Disk. For this proce-
dure, your instrument is equipped with additional
Sample RAM.
1. Insert the disk in the drive, press DISK and
select SINGLE SOUND from the main Load
page.
2. Press ENTER to gain access to the File Selec-
tor.
The floppy disk directory may show the pres-
ence of several blocks, one containing the
Sample, another User Styles, etc.. The in-
strument’s RAM directory shows the ROM
sounds of the first Group (Piano).
3. Select (if necessary) the Sample Block and
press ENTER to gain access.
LOAD SINGLE REAL PERFORMANCE
Loads a single Performance to any of the 64 lo-
cations of the Performance Groups (1-8). The
incoming Performances overwrite those in RAM.
The original factory-set Performances can be re-
stored at any time with the Restore Performance
operation.
LOAD SINGLE USER STYLE
Loads a single User Style and associated User
Style Performances to any location in the USER
Style Groups (1-4).
LOAD SINGLE STYLE PERFORMANCE
Loads a single bank of up to 8 user-programmed
Style Performances to the original ROM Style
Performance bank. These Performances can-
not be loaded to locations other than the original
source Style Performance bank. For example,
the Style Performances of Style 59 cannot be
loaded to any other location of the ROM Styles.
If you attempt to load to a destination other than
the correct one, a user message will inform you
of your error with the following message:
Press ESCAPE to close the message and try
again, this time selecting the correct destination.
LOAD SINGLE SOUND (EXAMPLE)
Use a disk known to contain a Sample to load to
memory, or load from Hard Disk. For this proce-
dure, your instrument is equipped with additional
Sample RAM.
1. Insert the disk in the drive, press DISK and
select SINGLE SOUND from the main Load
page.
2. Press ENTER to gain access to the File Selec-
tor.
The floppy disk directory may show the pres-
ence of several blocks, one containing the
Sample, another User Styles, etc.. The in-
strument’s RAM directory shows the ROM
sounds of the first Group (Piano).
3. Select (if necessary) the Sample Block and
press ENTER to gain access.
○○○○○○○○○○○○○○○○○○○○○○
Disk 4•7
○○○○○○○○○○○○○○○○○○○○○○
Disk 4•7
In the display example of the previous page,
the disk directory shows the presence of one
Percussive Sample (GRV.bpm 106) with Pr.
Change and Bank Select number 114-6.
4. Select (if necessary) the Sample and its
corresponding destination in RAM (114-6).
Use the +/– Page/Bank buttons to scroll the
Sound Groups (1, 2, … 15, 16). In this case,
scroll to Group 15 (Percussive - example A).
Use the directional arrows to scroll to the
desired Bank (in this case, bank 6) and des-
tination (Program Change 114 - example B).
5. Press ENTER twice to load the Sample file to
memory.
Note: It is recommended to load Sounds and Sam-
ples to their original locations to facilitate the on-board
file search facilities, but you are free to load them to
any Group.
LOAD GROUP
The Load Group command offers a quick way of
loading a Groups of 8 elements at a time.
Warning: The Group currently in memory is
overwritten by the incoming Group. If, for example,
the User Style Group you are loading contains only
one User Style, all User Styles of the destination
Group currently in RAM will be cancelled and replaced
by the new Group. Be sure that your Group data are
safely saved to Disk or Hard Disk before proceeding.
Load Group offers the following possibilities:
LOAD GROUP REAL PERFORMANCE
Loads a Group of up to 8 user-programmed Per-
formances to any Performance Group destina-
tion (1 - 8).
LOAD GROUP USER STYLE
Loads a Group of up to 8 User Styles (and corre-
sponding Performances) to any User Group des-
tination.
LOAD GROUP SONG
Loads Songs as “virtual Groups” (Song Group 1
and Song Group 2 found in the Disk environment
only). Each virtual group corresponds to the first
8 or second 8 locations of the Song memory. In
fact, in normal conditions when you press the
Song button to select a Song, the song selection
display shows two columns, left and right. The
left column corresponds to the virtual Songs-
Group 1 and the right to Songs-Group 2. This
feature is particularly useful for the WX Series
Songs disks which contain Song Groups contain-
ing up to 8 Songs each.
LOAD GROUP STYLE PERFORMANCE
Loads a Group of 8 Style Performance banks,
each bank containing up to 8 user-programmed
Style Performances. Unlike other Groups, the
Style Groups cannot be “switched” - they must
be loaded to their original locations in memory.
A
B
In the display example of the previous page,
the disk directory shows the presence of one
Percussive Sample (GRV.bpm 106) with Pr.
Change and Bank Select number 114-6.
4. Select (if necessary) the Sample and its
corresponding destination in RAM (114-6).
Use the +/– Page/Bank buttons to scroll the
Sound Groups (1, 2, … 15, 16). In this case,
scroll to Group 15 (Percussive - example A).
Use the directional arrows to scroll to the
desired Bank (in this case, bank 6) and des-
tination (Program Change 114 - example B).
5. Press ENTER twice to load the Sample file to
memory.
Note: It is recommended to load Sounds and Sam-
ples to their original locations to facilitate the on-board
file search facilities, but you are free to load them to
any Group.
LOAD GROUP
The Load Group command offers a quick way of
loading a Groups of 8 elements at a time.
Warning: The Group currently in memory is
overwritten by the incoming Group. If, for example,
the User Style Group you are loading contains only
one User Style, all User Styles of the destination
Group currently in RAM will be cancelled and replaced
by the new Group. Be sure that your Group data are
safely saved to Disk or Hard Disk before proceeding.
Load Group offers the following possibilities:
LOAD GROUP REAL PERFORMANCE
Loads a Group of up to 8 user-programmed Per-
formances to any Performance Group destina-
tion (1 - 8).
LOAD GROUP USER STYLE
Loads a Group of up to 8 User Styles (and corre-
sponding Performances) to any User Group des-
tination.
LOAD GROUP SONG
Loads Songs as “virtual Groups” (Song Group 1
and Song Group 2 found in the Disk environment
only). Each virtual group corresponds to the first
8 or second 8 locations of the Song memory. In
fact, in normal conditions when you press the
Song button to select a Song, the song selection
display shows two columns, left and right. The
left column corresponds to the virtual Songs-
Group 1 and the right to Songs-Group 2. This
feature is particularly useful for the WX Series
Songs disks which contain Song Groups contain-
ing up to 8 Songs each.
LOAD GROUP STYLE PERFORMANCE
Loads a Group of 8 Style Performance banks,
each bank containing up to 8 user-programmed
Style Performances. Unlike other Groups, the
Style Groups cannot be “switched” - they must
be loaded to their original locations in memory.
A
B
