GEM SK760 User Manual

○○○○○○○○○○○○○○○○○○○○○○
8•4 Reference Guide
○○○○○○○○○○○○○○○○○○○○○○
8•4 Reference Guide
Pedalboard/Computer
The PEDALBOARD and COMPUTER connec-
tors cannot operate at the same time. Selecting
one renders the other inoperative.
To activate one of the two connectors, select the
corresponding option («Pedalboard» or «Com-
puter») with the cursor buttons.
PEDALBOARD
If you have purchased Generalmusic’s optional
13-note pedalboard, connect it to the Pedalboard
connector and program the unit for how it will be
used by pressing F8 («Mode»).
MODE (F8) FOR PEDALBOARD OPTIONS
Options for the pedalboard.
Off - Pedalboard deactivated.
Pedalbass - The automatic bass of the auto-ac-
companiments is deactivated and the BASS track
is assigned to the Pedalboard, allowing you to
play the bass with the pedalboard.
Pedalchord - Chord recognition on the keyboard
is disabled and passed over to the pedalboard.
To play minor and sevenths, play two bass notes
at the same time. Alternatively, you can program
the Pedals 1, 2, or 3 to select minor and sev-
enths.
Multifunction - Each note of the pedalboard re-
calls a function associated to the Styles:
Edit General: PedalBoard/Computer
Note Function Note Function
C2 Start/Stop C#2 Tempo –
D2 Intro D#2 Tempo +
E2 Ending F2 Var 1
F#2 Fill < G2 Var 2
G#2 Fill = A2 Var 3
A#2 Fill > B2 Var 4
C3 Key Start
BASS SUSTAIN (F1)
Sustain for the notes of the pedalboard.
COMPUTER
Instead of using the MIDI interface, you can con-
nect via a single serial cable to a computer. Pro-
gram the connector for the type of computer used
by pressing F8 («Mode»).
Pedalboard/Computer
The PEDALBOARD and COMPUTER connec-
tors cannot operate at the same time. Selecting
one renders the other inoperative.
To activate one of the two connectors, select the
corresponding option («Pedalboard» or «Com-
puter») with the cursor buttons.
PEDALBOARD
If you have purchased Generalmusic’s optional
13-note pedalboard, connect it to the Pedalboard
connector and program the unit for how it will be
used by pressing F8 («Mode»).
MODE (F8) FOR PEDALBOARD OPTIONS
Options for the pedalboard.
Off - Pedalboard deactivated.
Pedalbass - The automatic bass of the auto-ac-
companiments is deactivated and the BASS track
is assigned to the Pedalboard, allowing you to
play the bass with the pedalboard.
Pedalchord - Chord recognition on the keyboard
is disabled and passed over to the pedalboard.
To play minor and sevenths, play two bass notes
at the same time. Alternatively, you can program
the Pedals 1, 2, or 3 to select minor and sev-
enths.
Multifunction - Each note of the pedalboard re-
calls a function associated to the Styles:
Edit General: PedalBoard/Computer
Note Function Note Function
C2 Start/Stop C#2 Tempo –
D2 Intro D#2 Tempo +
E2 Ending F2 Var 1
F#2 Fill < G2 Var 2
G#2 Fill = A2 Var 3
A#2 Fill > B2 Var 4
C3 Key Start
BASS SUSTAIN (F1)
Sustain for the notes of the pedalboard.
COMPUTER
Instead of using the MIDI interface, you can con-
nect via a single serial cable to a computer. Pro-
gram the connector for the type of computer used
by pressing F8 («Mode»).
○○○○○○○○○○○○○○○○○○○○○○
Quick Guide 1•37
○○ ○○○○○○○○○○○○○○○○○○○○
Quick Guide 1•37
Play with Effects or bypass them
You can temporarily modify the way in which a
Performance is processed by the on-board ef-
fect processor by changing the On/Off setting of
the Effects Off button.
BYPASS THE EFFECTS
1. To bypass the effects, press the EFFECTS OFF
button.
The LED of the button turns on, indicating
that the current Performance is no longer
processed by the Effects.
TO ACTIVATE THE EFFECTS
2. Press the active EFFECTS OFF button.
The LED of the button goes off to indicate
that the current Performance is processed by
the Effects.
You can find out more about the Effects and how
to assign them to the Performances, Style and
Song Performances in the Edit Effects section of
the Performance Chapter in the Reference Guide.
2
1
Play with Effects or bypass them
You can temporarily modify the way in which a
Performance is processed by the on-board ef-
fect processor by changing the On/Off setting of
the Effects Off button.
BYPASS THE EFFECTS
1. To bypass the effects, press the EFFECTS OFF
button.
The LED of the button turns on, indicating
that the current Performance is no longer
processed by the Effects.
TO ACTIVATE THE EFFECTS
2. Press the active EFFECTS OFF button.
The LED of the button goes off to indicate
that the current Performance is processed by
the Effects.
You can find out more about the Effects and how
to assign them to the Performances, Style and
Song Performances in the Edit Effects section of
the Performance Chapter in the Reference Guide.
2
1

GEM SK760 Specifications

General

Brand	GEM
Model	SK760
Category	Electronic Keyboard
Language	English
