PLAY WITH THE WHEELS
The on-board controlling devices include two
wheels on the left key block, both preset for Per-
formance functions.
The default configuration of the wheels is as fol-
lows:
• Wheel 1 (left) = Pitch Bend
• Wheel 2 (right) = Modulation
Wheel 1 is spring loaded to return to the central
position.
Wheel 2 is centre-dented in order to be able to
take it exactly at the central position.
The Wheels can be enabled or disabled to react
with the keyboard tracks of a Performance.
PLAY THE PROGRAMMABLE PADS
The four programmable Pads buttons (Pad 1, Pad
2, Pad 3, Pad 4) provide quick and easy ways of
adding extra sounds to your playing. You can
program each pad to produce an instrumental
sound, a percussive sound or sample. The pro-
grammable Pads can also be assigned to the
rotary slow/fast switching function.
• Strike the Pads freely.
While you play, add additional sounds from
the pads in real time.
The configuration of the Programmable Pads
can be stored in the Programmable Perform-
ances.
Pitch Bend
Modulation
WHEEL 1 WHEEL 2
