IMPORTANT PRELIMINARY NOTES
OBSERVE THESE IMPORTANT PRELIMINARY NOTES BEFORE USING YOUR INSTRUMENT:
AVOID PLACING DISKS NEAR MAGNETS - Do not place floppy disks on top of speakers, near mag-
nets, telephones, or other sources of electromagnetic fields. The disk contents could be damaged.=
MODELS WITH OPTIONAL HARD DISK INSTALLED- the hard disk may appear to operate rather
slowly the first time you open its directory. This is caused by operations relating to the organization of
the internal data and tests on the integrity of the device. The delay is eliminated on all successive hard
disk access operations. You may also find that the Hard Disk is write protected - this is merely a
precautionary measure to avoid accidental erasure of any factory-loaded files. The protection is re-
moved in the Disk Utility page.
UP-DATEABLE OPERATING SYSTEM - A disk containing the operating system is supplied with the
instrument. The disk can contain a more recent version of the operating system than the one contained
in the instrument’s Flash ROM.
To load the operating system contained on the floppy disk:
(1) turn off the instrument, (2) insert the floppy disk in the drive, (3) turn on the instrument, (4) When the
message «Loading OS-disk clears all memory!! ENTER to load, ESCAPE to abort» appears, press
ENTER to start the OS update, (5) wait while the operating system is being loaded, (6) when the mes-
sage «Loading successful (Enter to continue)» is displayed, press ENTER. After completing this proc-
ess, proceed with the power-up reset that follows below to insure proper operation.
RESETTING AT POWER UP - If the data contained in the instrument’s memory has been damaged,
either by being exposed to the effects of a strong magnetic field, or other unknown reason, the instru-
ment may not operate properly. The remedy is a power-up reset:
(1) Turn on the instrument while simultaneously pressing the POWER switch and rotating the DIAL, (2)
when the message «!!WARNING!! Dial on Power-Up Requests MEMORY CLEAR !! < ENTER to CLEAR
/ ESCAPE to abort>» appears, press ENTER to clear the MEMORY.
1
+
2
!!WARNING!! Dial on Power-Up
Requests MEMORY CLEAR !!
< ENTER to CLEAR / ESCAPE
to abort >
IMPORTANT INFORMATION
1. The SK760/880SE should contain the following items from the factory:
a) Instrument with power cord;
b) 1 Floppy disk containing the Operating System (OS-Disk);
c) Owner’s manual (shrink-wrap pack with 3-ring binder).
2. When contacting your retailer or authorized Generalmusic technical assistance centre, always
provide the model name and serial number of your instrument (found on the identification plate).
3. Generalmusic on Internet:
http://www.generalmusic.com
IMPORTANT PRELIMINARY NOTES
OBSERVE THESE IMPORTANT PRELIMINARY NOTES BEFORE USING YOUR INSTRUMENT:
AVOID PLACING DISKS NEAR MAGNETS - Do not place floppy disks on top of speakers, near mag-
nets, telephones, or other sources of electromagnetic fields. The disk contents could be damaged.=
MODELS WITH OPTIONAL HARD DISK INSTALLED- the hard disk may appear to operate rather
slowly the first time you open its directory. This is caused by operations relating to the organization of
the internal data and tests on the integrity of the device. The delay is eliminated on all successive hard
disk access operations. You may also find that the Hard Disk is write protected - this is merely a
precautionary measure to avoid accidental erasure of any factory-loaded files. The protection is re-
moved in the Disk Utility page.
UP-DATEABLE OPERATING SYSTEM - A disk containing the operating system is supplied with the
instrument. The disk can contain a more recent version of the operating system than the one contained
in the instrument’s Flash ROM.
To load the operating system contained on the floppy disk:
(1) turn off the instrument, (2) insert the floppy disk in the drive, (3) turn on the instrument, (4) When the
message «Loading OS-disk clears all memory!! ENTER to load, ESCAPE to abort» appears, press
ENTER to start the OS update, (5) wait while the operating system is being loaded, (6) when the mes-
sage «Loading successful (Enter to continue)» is displayed, press ENTER. After completing this proc-
ess, proceed with the power-up reset that follows below to insure proper operation.
RESETTING AT POWER UP - If the data contained in the instrument’s memory has been damaged,
either by being exposed to the effects of a strong magnetic field, or other unknown reason, the instru-
ment may not operate properly. The remedy is a power-up reset:
(1) Turn on the instrument while
simultaneously pressing the POWER switch and rotating the DIAL, (2)
when the message «!!WARNING!! Dial on Power-Up Requests MEMORY CLEAR !! < ENTER to CLEAR
/ ESCAPE to abort>» appears, press ENTER to clear the MEMORY.
1
+
2
!!WARNING!! Dial on Power-Up
Requests MEMORY CLEAR !!
< ENTER to CLEAR / ESCAPE
to abort >
IMPORTANT INFORMATION
1. The SK760/880SE should contain the following items from the factory:
a) Instrument with power cord;
b) 1 Floppy disk containing the Operating System (OS-Disk);
c) Owner’s manual (shrink-wrap pack with 3-ring binder).
2. When contacting your retailer or authorized Generalmusic technical assistance centre, always
provide the model name and serial number of your instrument (found on the identification plate).
3. Generalmusic on Internet:
http://www.generalmusic.com
○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•33
○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•33
00 0C 07 00 00 01 00 3E Pan -31 -> +31 3EH= 31
00 0C 08 00 00 01 00 03 AnalogOut 0
00 0C 09 00 00 01 00 01 Mic/Line On/Off 0
MIDI_CHANNELS ( xx = CHANNEL
3
= 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 0D 00 00 00 01 01 02 Midi_IN_Port 1 = MidiIn A, 2= MidiIn B 1=In A
xx 0D 01 00 00 01 01 10 Midi_IN_Ch 1->10 = channels 1->16
xx 0D 02 00 00 01 01 02 Midi_OUT_Port 1 = MidiOut A, 2= MidiOut B 1=Out A
xx 0D 03 00 00 01 01 10 Midi_OUT_Ch 1->10 = channels 1->16
(GENERAL) PEDALBOARD/COMPUTER MODE
Address(H) Size (H) Range(H) Parameter Description Default
00 0E 00 00 00 01 00 03 Computer Mode 0=Off, 1=Mac, 2=PC1, 3=PC3 0 = Off
00 0E 01 00 00 01 00 03 Pedalb. Mode 0=Off,1=Pdbass, 2=Pdchord, 3=MFun 0 = Off
00 0E 02 00 00 01 00 01 PcIfcPedB Mode switch 0
MIDI FILTERS IN ( xx = CHANNEL = 0 - 1F , Midi Lock ON )
Address(H) Size (H) Range(H) Parameter Description Default
xx 0F 00 00 00 01 00 64 filter_1 0 -> 100 (see Appendix C) 00H
xx 0F 01 00 00 01 00 64 filter_2 0 -> 100 (see Appendix C) 00H
xx 0F 02 00 00 01 00 64 filter_3 0 -> 100 (see Appendix C) 00H
xx 0F 03 00 00 01 00 64 filter_4 0 -> 100 (see Appendix C) 00H
xx 0F 04 00 00 01 00 64 filter_5 0 -> 100 (see Appendix C) 00H
xx 0F 05 00 00 01 00 64 filter_6 0 -> 100 (see Appendix C) 00H
xx 0F 06 00 00 01 00 64 filter_7 0 -> 100 (see Appendix C) 00H
MIDI FILTERS OUT ( xx = CHANNEL = 0 - 1F , Midi Lock ON )
Address(H) Size (H) Range(H) Parameter Description Default
xx 10 00 00 00 01 00 64 filter_1 0 -> 100 (see Appendix C) 00H
xx 10 01 00 00 01 00 64 filter_2 0 -> 100 (see Appendix C) 00H
xx 10 02 00 00 01 00 64 filter_3 0 -> 100 (see Appendix C) 00H
xx 10 03 00 00 01 00 64 filter_4 0 -> 100 (see Appendix C) 00H
xx 10 04 00 00 01 00 64 filter_5 0 -> 100 (see Appendix C) 00H
xx 10 05 00 00 01 00 64 filter_6 0 -> 100 (see Appendix C) 00H
xx 10 06 00 00 01 00 64 filter_7 0 -> 100 (see Appendix C) 00H
MIDI COMMON/ARRG NoteToArrang
Address(H) Size (H) Range(H) Parameter Description Default
00 11 00 00 00 01 00 10 Chord Ch.1 0=Off, 1->10 = chans 1->16 0 = Off
00 11 01 00 00 01 00 01 IN_1 0
00 11 02 00 00 01 00 10 Chord Ch.2 0=Off, 1->10 = chans 1->16 0 = Off
00 11 03 00 00 01 00 01 IN_2 0
MIDI CTRL PADS ( xx = CHANNEL = 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 12 00 00 00 01 00 01 ped_ftsw[1] 1
xx 12 01 00 00 01 00 01 ped_ftsw[2] 1
xx 12 02 00 00 01 00 01 ped_ftsw[3] 1
PRESET PARAMETERS
EFFECTS A
Address(H) Size (H) Range(H) Parameter Description Default
00 13 00 00 00 01 00 17 Eff_Type1 0 -> 23 5=St.Concert
00 13 01 00 00 01 00 7F eff_vol1 0 -> 127 5AH = 90
00 13 02 00 00 01 par#1_1
00 13 03 00 00 01 par#2_1
00 13 04 00 00 01 par#3_1
00 13 05 00 00 01 00 1F Eff_Type2 0 -> 31 9 = Chorus2
00 13 06 00 00 01 00 7F eff_vol2 0 -> 127 79H = 121
00 13 07 00 00 01 par#1_2
00 13 08 00 00 01 par#2_2
00 0C 07 00 00 01 00 3E Pan -31 -> +31 3EH= 31
00 0C 08 00 00 01 00 03 AnalogOut 0
00 0C 09 00 00 01 00 01 Mic/Line On/Off 0
MIDI_CHANNELS ( xx = CHANNEL
3
= 0 - 1F )
Address(H)
Size (H)
Range(H)
Parameter
Description
Default
xx 0D 00 00 00 01 01 02 Midi_IN_Port 1 = MidiIn A, 2= MidiIn B 1=In A
xx 0D 01 00 00 01 01 10 Midi_IN_Ch 1->10 = channels 1->16
xx 0D 02 00 00 01 01 02 Midi_OUT_Port 1 = MidiOut A, 2= MidiOut B 1=Out A
xx 0D 03 00 00 01 01 10 Midi_OUT_Ch 1->10 = channels 1->16
(GENERAL) PEDALBOARD/COMPUTER MODE
Address(H)
Size (H)
Range(H)
Parameter
Description
Default
00 0E 00 00 00 01 00 03 Computer Mode 0=Off, 1=Mac, 2=PC1, 3=PC3 0 = Off
00 0E 01 00 00 01 00 03 Pedalb. Mode 0=Off,1=Pdbass, 2=Pdchord, 3=MFun 0 = Off
00 0E 02 00 00 01 00 01 PcIfcPedB Mode switch 0
MIDI FILTERS IN ( xx = CHANNEL = 0 - 1F , Midi Lock ON )
Address(H)
Size (H)
Range(H)
Parameter
Description
Default
xx 0F 00 00 00 01 00 64 filter_1 0 -> 100 (see Appendix C) 00H
xx 0F 01 00 00 01 00 64 filter_2 0 -> 100 (see Appendix C) 00H
xx 0F 02 00 00 01 00 64 filter_3 0 -> 100 (see Appendix C) 00H
xx 0F 03 00 00 01 00 64 filter_4 0 -> 100 (see Appendix C) 00H
xx 0F 04 00 00 01 00 64 filter_5 0 -> 100 (see Appendix C) 00H
xx 0F 05 00 00 01 00 64 filter_6 0 -> 100 (see Appendix C) 00H
xx 0F 06 00 00 01 00 64 filter_7 0 -> 100 (see Appendix C) 00H
MIDI FILTERS OUT ( xx = CHANNEL = 0 - 1F , Midi Lock ON )
Address(H)
Size (H)
Range(H)
Parameter
Description
Default
xx 10 00 00 00 01 00 64 filter_1 0 -> 100 (see Appendix C) 00H
xx 10 01 00 00 01 00 64 filter_2 0 -> 100 (see Appendix C) 00H
xx 10 02 00 00 01 00 64 filter_3 0 -> 100 (see Appendix C) 00H
xx 10 03 00 00 01 00 64 filter_4 0 -> 100 (see Appendix C) 00H
xx 10 04 00 00 01 00 64 filter_5 0 -> 100 (see Appendix C) 00H
xx 10 05 00 00 01 00 64 filter_6 0 -> 100 (see Appendix C) 00H
xx 10 06 00 00 01 00 64 filter_7 0 -> 100 (see Appendix C) 00H
MIDI COMMON/ARRG NoteToArrang
Address(H)
Size (H)
Range(H)
Parameter
Description
Default
00 11 00 00 00 01 00 10 Chord Ch.1 0=Off, 1->10 = chans 1->16 0 = Off
00 11 01 00 00 01 00 01 IN_1 0
00 11 02 00 00 01 00 10 Chord Ch.2 0=Off, 1->10 = chans 1->16 0 = Off
00 11 03 00 00 01 00 01 IN_2 0
MIDI CTRL PADS ( xx = CHANNEL = 0 - 1F )
Address(H)
Size (H)
Range(H)
Parameter
Description Default
xx 12 00 00 00 01 00 01 ped_ftsw[1] 1
xx 12 01 00 00 01 00 01 ped_ftsw[2] 1
xx 12 02 00 00 01 00 01 ped_ftsw[3] 1
PRESET PARAMETERS
EFFECTS A
Address(H)
Size (H)
Range(H)
Parameter
Description Default
00 13 00 00 00 01 00 17 Eff_Type1 0 -> 23 5=St.Concert
00 13 01 00 00 01 00 7F eff_vol1 0 -> 127 5AH = 90
00 13 02 00 00 01 par#1_1
00 13 03 00 00 01 par#2_1
00 13 04 00 00 01 par#3_1
00 13 05 00 00 01 00 1F Eff_Type2 0 -> 31 9 = Chorus2
00 13 06 00 00 01 00 7F eff_vol2 0 -> 127 79H = 121
00 13 07 00 00 01 par#1_2
00 13 08 00 00 01 par#2_2
