THE DEFAULT DISPLAY: “SOUND VIEW” PAGE
This type of page shows the Sounds assigned to the tracks. «Sound View» is the default viewing mode.
A typical Sound View page appears in Style/RealTime mode (other Sound View pages showing slight
variations appear in Song mode and Style and Song recording modes).
a
b c
e
f g
h
d
a. Track status icons. Select the tracks with the Soft buttons A...H or with the cursor buttons / .
b. Sound names. The name of the Group to which the Sound belongs appears close to the Sound
name, or (in order) the ProgramChange, BankSelect MSB, BankSelect LSB numbers. Tracks which
are not assigned to internal sounds show a string of dashes (------) instead of the Sound name.
If the track has been modified with «Edit Perf Sound», the symbol appears after the Sound name.
c. Menu or Function list. Contains options which can be selected with the Soft buttons F1...F8. In
Style/RealTime mode the soft buttons are coupled (F1/F2, F3/F4, F5/F6, F7/F8) and the menu
shows the options to select:
• the track status (Full, Upp/Low, Multi).
• the Split Point. The keyboard area below the split point corresponds to the chord recognition zone
for the automatic accompaniment.
d. Status bar showing general information.
e. Style and Performance name (Performance or Style-Performance, depending on whether SIN-
GLE TOUCH PLAY is on or off). Song mode: Song and Song-Performance name.
A Performance that has been modified but not saved with STORE PERFORMANCE is identified by
the symbol [‘]. A ROM Style with a modified Style-Performance is identified by the symbol [*].
f. Tempo (varied with the DIAL).
g. Locator (measure and beat counter). In Style mode this parameter monitors the Style pattern (riff).
h. Chord - the current recognized Chord symbol.
THE DEFAULT DISPLAY: “SOUND VIEW” PAGE
This type of page shows the Sounds assigned to the tracks. «Sound View» is the default viewing mode.
A typical Sound View page appears in Style/RealTime mode (other Sound View pages showing slight
variations appear in Song mode and Style and Song recording modes).
a
b c
e
f
g
h
d
a. Track status icons. Select the tracks with the Soft buttons A...H or with the cursor buttons
/ .
b. Sound names. The name of the Group to which the Sound belongs appears close to the Sound
name, or (in order) the ProgramChange, BankSelect MSB, BankSelect LSB numbers. Tracks which
are not assigned to internal sounds show a string of dashes (------) instead of the Sound name.
If the track has been modified with «Edit Perf Sound», the symbol
appears after the Sound name.
c. Menu or Function list. Contains options which can be selected with the Soft buttons F1...F8. In
Style/RealTime mode the soft buttons are coupled (F1/F2, F3/F4, F5/F6, F7/F8) and the menu
shows the options to select:
• the track status (Full, Upp/Low, Multi).
• the Split Point. The keyboard area below the split point corresponds to the chord recognition zone
for the automatic accompaniment.
d. Status bar showing general information.
e. Style and Performance name (Performance or Style-Performance, depending on whether SIN-
GLE TOUCH PLAY is on or off). Song mode: Song and Song-Performance name.
A Performance that has been modified but not saved with STORE PERFORMANCE is identified by
the symbol [‘]. A ROM Style with a modified Style-Performance is identified by the symbol [*].
f. Tempo (varied with the DIAL).
g. Locator (measure and beat counter). In Style mode this parameter monitors the Style pattern (riff).
h. Chord - the current recognized Chord symbol.
