Gilera GP 800 i.e. - Page 138

- Remove the stand rear pin and collect the wash-
er.
- Remove the centre stand plus the four bushings.
- Unscrew the nut fastening the front pin.
- Unscrew the front pin and collect the washer.
- The attachment plate of the centre stand is now
free. For size reasons, it can only be removed after
being released from the catalytic converter retain-
ers.
Engine from vehicle GP 800 i.e.
ENG VE - 4
