- The stand fixing pins also fasten the muffler sup-
porting bracket.
- Undo the upper screw fixing it to the engine, and
the muffler supporting arm is now free.
- Release the muffler supporting arm from the cat-
alytic converter.
- Unscrew the two nuts fixing the front exhaust
manifold.
- Unscrew the nut indicated, loosen the clamp, and
remove the front exhaust manifold together with
the gasket and the graphite bushing.
GP 800 i.e. Engine from vehicle
ENG VE - 5
