Gilera GP 800 i.e.

To Next Page

To Previous Page

- Undo the two screws and remove the oil pump

cover.

- Slide off the shaft together with the driving pins

of the rotors.

- Remove the two rotors and wash them thorough-

ly.

GP 800 i.e. Engine

ENG - 91
