Stores code Description

020431Y Valve oil seal extractor

020128Y Piston fitting band

020470Y Pin retainers installation tool

020475Y Piston position checking tool

020512Y Piston fitting fork

020478Y Punch for driven pulley roller cas-

ing

GP 800 i.e. Tooling

TOOL - 3
