Gilera GP 800 i.e.

To Next Page

To Previous Page

Stores code Description

020565Y Flywheel lock calliper spanner

020659Y Tool to remove clutch and re-

place belt

020660Y Driving pulley lock

020713Y Flywheel extractor

020527Y Engine support base

020658Y Engine plate

Tooling GP 800 i.e.

TOOL - 4
