Gilera GP 800 i.e.

To Next Page

To Previous Page

Stores code Description

020664Y Flywheel side crankshaft fitting

tip

020665Y Transmission side crankshaft fit-

ting tip

020709Y Engine support

020460Y Scooter diagnosis and tester

020469Y Reprogramming kit for scooter

diagnosis tester

020661Y Water pump overall seal replace-

ment kit

GP 800 i.e. Tooling

TOOL - 5
