Gilera GP 800 i.e.

To Next Page

To Previous Page

Stores code Description

020150Y Air heater support

020151Y Air heater

001467Y003 Nut

001467Y004 Lug / Taper pin

001467Y005 Screw

001467Y006 Pliers to extract 20 mm bearings

020467Y020 Pliers to extract 30 mm bearings

GP 800 i.e. Tooling

TOOL - 9
