Gilera GP 800 i.e.

To Next Page

To Previous Page

Stores code Description

001467Y001 Pliers to extract 25 mm Ø bear-

ings

001467Y008 Pliers to extract 17 mm ø bear-

ings

001467Y014 Pliers to extract ø 15-mm bear-

ings

020357Y 32 x 35 mm adaptor

020358Y 37x40-mm adaptor

020359Y 42x47-mm adaptor

020360Y Adaptor 52 x 55 mm

020655Y Adaptor 62x68 mm

020670Y Adaptor 34 mm

Tooling GP 800 i.e.

TOOL - 10
