GW Instek GDM-906 Series User Manual

GDM-906X Series User Manual
100
Operation
Press the F3 (Math) key to show the
mathematical analysis as the figure below.
View Data
+000.5625
mVDC
Indicates the currently measured
mVDC value
Low Limit
Indicates the defined low limit
Low Fail
Indicates the counts of below
the defined low limit
High Limit
Indicates the defined high limit
High Fail
Indicates the counts of above
the defined high limit
Show
Math+STAT
result
Background
The Math+STAT page in MathDisp
allows you to view data from both
statistical calculations and mathematical
analysis.
Operation
Press the F4 (Math+STAT) key
to show the hybrid page of
Math & STAT instantly as figure below.
View Data
+0.001003 VDC
Indicates the currently
measured mVDC value
Blue Section
It is identical to the contents
of STAT display. Refer to the
previous chapter for details.
