GW Instek GDM-906 Series User Manual

REMOTE CONTROL
211
3
Output
Transmit
Data (TxD)
4
Output
Data
Terminal
Ready (DTR)
5
-
Signal
Ground (SG)
6
Input
Data Set
Ready (DSR)
7
Input
Request To
Send (RTS)
8
Output
Clear To Send
(CTS)
9
------
No
Connection
PC Connection
Use a Null-Modem connection as the diagram below shown.
