REMOTE CONTROL
271
DATA[X]:LAST?
Returns the last measurement value with units taken. You can execute this
query at any time, even during a series of measurements.
X = null or 1 indicate 1
st
display value, X = 2 indicate 2
nd
display value
Return parameter: <NRf>, Ex: +0.15900000E+01 VDC
●If no data is available, +9.91000000E+37 (Not a Number) is returned with
units
DATA:POINts?
Returns the total number of measurements currently in reading memory.
Return parameter: <NR1>, Ex: +100
●You can store up to 10,000 measurements values in the reading memory of
the GDM-9060 or 100,000 measurements values on the GDM-9061.
DATA:POINts:EVENt:THReshold
Sets the threshold for event number of measurement.
Parameter: <NR1> GDM-9060 : 1-10,000 / GDM-9061 : 1- 100,000
Example: DATA:POIN:EVEN:THR 10
Sets the event threshold to 10.
●When measurement numbers reach the set threshold, the Bit9 within the
Operater Event Register (STATus:OPERation:EVENt.) will be set as 1.
●Once the Memory Threshold bit (bit 9 in the Standard Operation Event
register) is set, it remains set until cleared by STATus:OPERation:EVENt? or
*CLS.
DATA:POINts:EVENt:THReshold?
Returns the event threshold number.
Return parameter: <NR1>, Ex: +10
