CONFigure2[:VOLTage]:AC
Sets measurement to AC Voltage on the 2
nd
display and specifies range.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX | DEF)]
Example: CONF2:VOLT:AC
Sets the measurement mode to AC voltage on the 2
nd
display.
CONFigure2:CURRent[:DC]
Sets measurement to DC Current on the 2
nd
display and specifies
range/resolution.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX |
DEF),Resolution(<NRf> | MIN | MAX | DEF)]
Example: CONF2:CURR:DC 10e-3,DEF
Sets the DC current range to 10mA using the default resolution on the 2
nd
display.
●Autoranging (AUTO or DEFault), will generate an error if you specify a
<resolution> because the instrument cannot accurately resolve the
integration time (especially if the input continuously changes). If your
application requires autoranging, specify DEFault for the <resolution> or
omit the <resolution> altogether.
CONFigure2:CURRent:AC
Sets measurement to AC Current on the 2
nd
display and specifies range.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX | DEF)]
Example: CONF2:CURR:AC 10e-2
Sets the measurement mode to AC Current with a 100mA range on the 2
nd
display.
CONFigure2:FREQuency
Sets measurement to Frequency on the 2
nd
display and specifies range.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX | DEF)]
Example: CONF2:FREQ MAX
Sets the frequency range to max on the 2
nd
display.
CONFigure2:PERiod
Sets measurement to Period on the 2
nd
display and specifies the range.
Parameter: [None] | [Range(<NRf> | MIN | MAX | DEF)]
Example: CONF2:PER
Sets the measurement mode to period measurement using the auto range
on the 2
nd
display.
CONFigure2:OFF
Turns the 2
nd
display function off.
Parameter: [None]
