GW Instek GDM-906 Series User Manual

REMOTE CONTROL
269
CONFigure:CONTinuity
Sets measurement to Continuity on the 1
st
display.
Parameter: [None]
CONFigure:DIODe
Sets measurement to Diode on the 1
st
display.
Parameter: [None]
CONFigure:TEMPerature
Sets measurement to Temperature on the 1
st
display and specifies
type/resolution.
Parameter: [None] | [<Probe type>, <Type>, 1, Resolution(<NRf> | MIN |
MAX | DEF)]
<Probe type>:TCOuple, RTD, FRTD, THERmistor, FTHermistor.
<Type>:
Tcouple: J | K | N | R | S | T | B | E | USER
RTD / FRTD : PT100 | D100 | F100 | PT385 | PT3916 | USER
Thermistor / Fthermistor : 2.2kΩ | 5kΩ | 10kΩ | USER
Example: CONF:TEMP TCO,K
Sets the measurement mode to TCO with a type K sensor.
●Autoranging (AUTO or DEFault), will generate an error if you specify a
<resolution> because the instrument cannot accurately resolve the
integration time (especially if the input continuously changes). If your
application requires autoranging, specify DEFault for the <resolution> or
omit the <resolution> altogether.
Secondary Display: CONFigure2 Commands
CONFigure2[:VOLTage]:DC
Sets measurement to DC Voltage on the 2
nd
display and specifies
range/resolution.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX |
DEF),Resolution(<NRf> | MIN | MAX | DEF)]
Example: CONF2:VOLT:DC 1,MAX
Sets the voltage range to 1 volt and the resolution to the maximum.
●Autoranging (AUTO or DEFault), will generate an error if you specify a
<resolution> because the instrument cannot accurately resolve the
integration time (especially if the input continuously changes). If your
application requires autoranging, specify DEFault for the <resolution> or
omit the <resolution> altogether.
