GDM-906X Series User Manual
268
CONFigure:RESistance
Sets measurement to 2-wire Resistance on the 1
st
display and specifies
range/resolution.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX |
DEF),Resolution(<NRf> | MIN | MAX | DEF)]
Example: CONF:RES 10e3,MIN
Sets the measurement mode to 2-wire Resistance with a 10kΩ range at the
lowest resolution.
●Autoranging (AUTO or DEFault), will generate an error if you specify a
<resolution> because the instrument cannot accurately resolve the
integration time (especially if the input continuously changes). If your
application requires autoranging, specify DEFault for the <resolution> or
omit the <resolution> altogether.
CONFigure:FRESistance
Sets measurement to 4-wire Resistance on the 1
st
display and specifies the
range/resolution.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX |
DEF),Resolution(<NRf> | MIN | MAX | DEF)]
Example: CONF:FRES 1e3,MAX
Sets the measurement mode to 4-wire Resistance with a range of 1kΩ at the
maximum resolution.
●Autoranging (AUTO or DEFault), will generate an error if you specify a
<resolution> because the instrument cannot accurately resolve the
integration time (especially if the input continuously changes). If your
application requires autoranging, specify DEFault for the <resolution> or
omit the <resolution> altogether.
CONFigure:FREQuency
Sets measurement to Frequency on the 1
st
display and specifies range.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX | DEF)]
Example: CONF:FREQ MAX
Sets the frequency range to max.
CONFigure:PERiod
Sets measurement to Period on the 1
st
display and specifies
range/resolution.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX | DEF)]
Example: CONF:PER
Sets the measurement mode to period with a auto range.
CONFigure:CAPacitance
Sets measurement to Capcitance on the 1
st
display and specifies range.
Parameter: [None] | [Range(<NRf> | AUTO | MIN | MAX | DEF),]
Example: CONF:CAP 10e-7
Sets the Capcitance range to 100nF.
